Magnetic Separation Rack

6 Holes Magnetic Separation Rack

Six-hole magnetic stand is suitable for magnetic bead separation experiments in 1.5-2ml centrifuge tubes. The average magnetic separation time is 30 seconds, and it can quickly separate nucleic acids, proteins, cells and other substances.

The magnetic stand is specially developed to cooperate with the magnetic beads. It can efficiently separate the magnetic beads. Put a 1.5-2ml centrifuge tube on the magnetic stand, and the magnetic separation process can be completed in an average of 30 seconds, so as to achieve the purpose of rapidly separating and purifying substances such as cells, proteins or nucleic acids. This product adopts a humanized inclination design, which enables the centrifuge tube to be close to the magnetic stand, making the separation process intuitive and convenient.


     1. High Efficiency: The magnetic field strength is high, the average magnetic separation time is 30 seconds, and the separation process is fast and efficient.

     2. Convenient operation: The humanized inclination design makes the centrifuge tube close to the magnetic frame, which is more convenient for the separation process.

     3. Small and durable: The unique material makes the magnetic frame lightweight and durable.


        1. Place the combined centrifuge tube containing the magnetic bead-target mixture to be separated on a magnetic stand.

        2. Stand still for 30 seconds until the magnetic beads are sucked to the wall of the centrifuge tube.

        3. Carefully pour out the liquid, or use a pipette to remove the liquid.

        4. Take the centrifuge tube out of the magnetic rack and put it back into the ordinary centrifuge tube rack to complete the magnetic separation operation.

磁力架 (3)

Additional Information

Specifications (mm): 80×49×48

Aperture: 12mm Suitable for 1.5-2 ml centrifuge tubes

Optimum working volume: 10-2000ul
